16-channel NVR | DS-7616NI-I2

16-ch 1U 4K NVR\r\nDS-7616NI-I2\r\n\r\nProfessional and Reliability\r\n

\r\n
• H.265+ compression effectively reduces the storage space by up to 75%
\r\n
• Dual-stream recording saves bandwidth
\r\n
• Adopt stream over TLS encryption technology which provides more secure stream transmission service
\r\n
• Support double verification for playback and downloading
\r\n

\r\nHD Video Output\r\n

\r\n
• Provide independent HDMI and VGA outputs
\r\n
• HDMI video output at up to 4K resolution
\r\n

\r\nStorage and Playback\r\n

\r\n
• Up to 2 SATA interfaces for HDD connection
\r\n
• 8/16-ch synchronous playback
\r\n

\r\nSmart & POS Function\r\n

\r\n
• Support multiple VCA (Video Content Analytics) events
\r\n
• Configurable special camera smart functions, such as VCA detection (motion, line crossing, intrusion, etc.), heat map, ANPR, and people counting
\r\n
• POS information overlay on live view and playback, and POS triggered recording and alarm
\r\n

\r\nNetwork & Ethernet Access\r\n

\r\n
• 1 self-adaptive 10/100/1000 Mbps Ethernet interface
\r\n
• Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
\r\n
• Smooth streaming technology
\r\n
• Support web access without plug-in
\r\n

\r\nProduct Specifications\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n\r\n

\r\n IP video input \r\n	\r\n 16-ch\r\nUp to 32 MP resolution\r\n*: After ultra HD resolution mode is enabled, the NVR supports up to 4-ch 32 MP/24 MP IP video inputs \r\n
\r\n Incoming bandwidth \r\n	\r\n 160 Mbps \r\n
\r\n Outgoing bandwidth \r\n	\r\n 256 Mbps \r\n
\r\n HDMI output \r\n	\r\n 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz \r\n
\r\n VGA output \r\n	\r\n 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz \r\n
\r\n Video output mode \r\n	\r\n HDMI/VGA independent output \r\n
\r\n Decoding format \r\n	\r\n H.265+/H.265/H.264+/H.264/MPEG4 \r\n
\r\n Recording resolution \r\n	\r\n 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF \r\n*: After ultra-HD resolution mode is enabled, the NVR supports up to 4-ch 32 MP/24 MP IP video inputs. \r\n
\r\n Synchronous playback \r\n	\r\n 16-ch \r\n
\r\n Capability \r\n	\r\n 1-ch@32 MP (30 fps)/2-ch@12 MP (20 fps)/4-ch@8 MP (25 fps)/8-ch@4 MP (30 fps)/16-ch@1080p (30 fps) \r\n
\r\n SATA \r\n	\r\n 2 SATA interfaces \r\n
\r\n Capacity \r\n	\r\n Up to 10 TB capacity for each disk \r\n
\r\n Dimension (W × D × H) \r\n	\r\n 385 × 315× 52 mm (15.2\" × 12.4\" × 2.0\") \r\n
\r\n Weight (without HDD) \r\n	\r\n ≤ 1 kg (2.2 lb) \r\n

\r\nDownload Datasheet
